Products
Boutique - USB Power Supply Plug
Single Socket And USB Power Supply Socket Box
SC-568
1. Standard USB socket
2. Dust cover "(waterproof) USB socket & socket"
3. Thermal power-off device protection mechanism (USB socket)
4. General fixed nuts (both)
5. Input voltage DC12V-24V
6. Output voltage DC5V±5%
7. Output current 2.1A (maximum)
8. Material DuPont nylon + 30% fiber
9. Double socket panel and mounting screws
10. 12 volt outlet
11. Insert the socket into the installation position, and then lock the ordinary nut inside the installation position.
Lock the fixing screws (2 screws) to fix them on the fixing panel
12. Dual power switch controls USB socket and socket power supply
Specification
