KCRS Spring Operated Cable Reels
|
Model |
KCRS 1 |
KCRS 11 |
KCRS 2W |
KCRS 3W |
KCRS 4W |
KCRS 4F |
KCRS 5F |
KCRS 5T |
|
Input hole dia mm |
14 |
13 |
13 |
13 |
22 |
22 |
26 |
26 |
|
Turns (circle) |
15 |
13 |
22 |
35 |
25 |
50 |
50 |
35 |
|
Max reel torque kgf. m |
0.16 |
0.3 |
086 |
0.4 |
1.06 |
1.07 |
1.76 |
30 |
|
Cable Type mm2 x C |
2 x 3 |
2 x 3 |
3.5 x 3 |
3.5x3 |
8 x 3 |
8 x 3 |
8 x 3 |
14 x 3 |
|
Max. length of cable m |
10 |
13 |
18 |
25 |
18 |
38 |
48 |
26 |
|
Max. Amp of cable |
15 |
15 |
30 |
30 |
40 |
40 |
40 |
60 |
|
Max. pole of cable |
8 |
8 |
12 |
12 |
16 |
16 |
16 |
16 |
KCRM Motorized Cable Reels
T20 Type
|
Model |
50 m |
60 m |
70 m |
80 m |
90 m |
100 m |
110 m |
|
14mm2x3C |
T20H-0514 |
T20H-0714 |
T20H-0914 |
||||
|
14mm2x4C |
T20H-0714 |
T20H-0914 |
|||||
|
22mm2x3C |
T20H-1322 |
T20H-0714 |
|||||
|
22mm2x4C |
T20H-1322 |
- |
|||||
|
38mm2x3C |
T20H-1338 |
T20H-0714 |
- |
||||
|
38mm2x4C |
T20H-1388 |
T20H-0714 |
- |
||||
T20.1 type/T40 type
|
Model |
50-70 m |
80-90 m |
100 m |
110 m |
120-140 m |
150-160 m |
|
22mm2x3C |
|
|
|
|
T20.1H-1822 |
T40M-1822 |
|
38mm2x3C |
|
|
|
T40M-1838 |
T40M-2038 |
|
|
60mm2x3C |
T20.1H-1560 |
T40M-1860 |
T40M-2060 |
T40M-2060 |
T40M-2060 |
|
|
100mm2x3C |
T40M-2099 |
|
|
|
|
|
T20.1 type/T40 type
|
Model |
Max. dia. of cable |
Max. length of cable |
|
KCRM-M50 |
60 mm2 |
200 mm2 |
|
100 mm2 |
100 mm2 |
T10 type/M15 type
|
Model |
Max. pole of cable |
Max. dia. of cable |
Max. length of cable |
|
KCRM-M10S-0505-0814 |
15 |
5.5 mm2 – 14 mm2 |
50 m – 100 m |
|
KCRM-M10S-0705-0514 |
15 |
||
|
KCRM-M15S-0905-0914 |
10 |
T30 type/M30.1 type
|
Model |
Max. pole of cable |
Max. dia. of cable |
Max. length of cable |
|
KCRM-M30H-1314-1322 |
4 |
14 mm2 – 38 mm2 |
50 m – 100 m |
|
KCRM-M30.1H-1322-1338 |
|||
|
KCRM-M30.1H5-1838 |
Cable Reference Table
|
No. of Cord |
Cable Dia. mm |
||||||||||||
|
1.25 |
2.0 |
3.5 |
5.5 |
8.0 |
14.0 |
22.0 |
30.0 |
38.0 |
50.0 |
60.0 |
80.0 |
100.0 |
|
|
Cable O.D. mm |
|||||||||||||
|
3C |
11.5 |
12.5 |
14 |
15.5 |
17.0 |
22.0 |
28.0 |
33.0 |
35.0 |
39..0 |
42.0 |
49.0 |
54.0 |
|
4C |
13.0 |
13.2 |
15.5 |
17.5 |
19.0 |
25.0 |
31.0 |
36.0 |
39.0 |
43.0 |
47.0 |
55.0 |
60.0 |
