■ Fuse current: Voltage 750V.DC 200A - 400A ; Voltage 500V.DC 500A ■ Current Rating : 250A
Features / Application :
■ MSD7 provides stable high voltage power transmission for EV/HEV systems. The fuses in MSD7 provides overcurrent and short-ci「cuit protection.
■ Breaking structure and fuses are highly integrated inside which saves installation space and convenient for repair and maintenance.
■ MSD7 is connector comprising of plug and jack. The jack is joint with cable. Back installation of socket for option.
■ Current rating 250A and 300A in 30 mins, catch one pair of HVI L
■ The connectors have rotatable locking handle and secondary lock-unlock structure, it's convenient to operate and save strength.
